J75 Thermal Break Pivot Door
-
The J75 Thermal Break Pivot Door is a statement-making aluminum pivot door engineered for oversized entry applications. Heavy-duty pivot hardware and thermal break profile allow doors up to 3+ meters tall while retaining energy performance and daily usability.
Key Features
- Transform your space with a bold, frameless design. The hidden pivot system and ultra-narrow profiles create a seamless, architectural statement perfect for contemporary homes or luxury commercial spaces
- Break free from standard sizes! Our pivot doors support oversized dimensions (up to 4m+ in height/width) and custom finishes—ideal for grand entrances, floor-to-ceiling glass panels, or bespoke material combinations (e.g., wood-aluminum, tinted glass)
- Engineered for durability, the precision pivot mechanism distributes weight evenly, enabling effortless 180-degree rotation even for heavy doors. High-grade bearings ensure whisper-quiet movement and decades of reliable use
- Maximize your layout efficiency! Unlike traditional hinged doors, pivot doors rotate on a central axis, requiring no clearance space—perfect for tight areas. Choose inward/outward swing or dual-directional opening for flexible traffic flow
- Built to perform: Multi-layer seals and thermal-break aluminum frames reduce heat loss and noise infiltration. Reinforced locking systems and robust construction offer enhanced security for peace of mind
Technical Specifications
| Frame Material | Extruded aluminum alloy, thermal break profile |
| Glazing | Double or triple insulated glass; low-E and tempered options are available per project. |
| Weatherstripping | EPDM rubber gaskets, multi-line sealing |
| Colors / Finishes | Matte black, charcoal, bronze, white, wood-grain, RAL custom |
| Custom Sizes | Manufactured to your finished opening dimensions |
| Lead Time | Lead time is confirmed per project in your quotation. |
Full technical spec sheet — including detailed dimensions, glass options, hardware brands, and performance testing data — is available on request.
Typical Applications
- Signature entrances for luxury villas and boutique hotels
- Modern minimalist architecture where oversized doors are the focal point
- Commercial lobbies requiring high-traffic durability and design impact
- Custom-scale doorways up to 3+ meters tall
Frequently Asked Questions
What is the maximum size for a pivot door?
Single-panel pivot doors up to 3.5m tall × 1.5m wide are standard. Larger dimensions are engineered per project. Weight capacity of the pivot hardware determines the practical maximum.
Where does the pivot point sit?
Standard offset is 1/4 of the width from the hinge side. Center-pivot configurations are also available for symmetric visual impact but reduce the effective clear opening.
What hardware is used?
Heavy-duty floor and top pivot hardware rated for the door weight, with concealed installation. Optional soft-close and self-closing mechanisms available.
Can this be used as a main entry door with security lock?
Yes. Multi-point locking, high-security cylinders, and reinforced strike hardware are available for entry-door applications.
Is a matching sidelight or transom available?
Yes. The pivot door series can be paired with fixed frames from the same profile family for a unified architectural expression.
Request a Free Quote
Send us your project dimensions, quantity, and target color / finish. Our engineering team reviews your request and replies with a detailed quotation and shop drawing.
